Indoor Digital Menu Board

Site Survey for XDMB Controllerless Solution
This survey is to be filled out once for each restaurant and should be completed by someone with considerable knowledge of the restaurant equipment and environment while they are on-site. Providing accurate information on this survey is the best way to prevent issues that could prevent a succesful installation and cause additional costs to the restaurant.

The purpose of this survey is to confirm the site is prepped and ready for the Xenial Indoor Digital Menu Board and will allow an install date to be provided.

If you have any questions on how to complete this survey, please reach out to Xenial Installation department at sic.installadmin@xenial.com and someone will reach out to assist.
Site Information
Brand*
Restaurant Number*
Restaurant Phone Number*
Restaurant E-mail
Point of Contact for Installation Information/Questions
Contact Name*
Contact Title*
Contact E-mail*
Contact Phone Number*
Network Area/Network Information

You may need to confirm some of this information with your Restaurant IT.
Is the network equipment located in the office?*

YesNo
If No, where is the site's network equipment located?
Make & model of Internet router/firewall/etc. that we are plugging into for network connectivity? *
What port(s) number(s) are we using on the above device? *
IP/Address/IP Range*
Subnet Mask*
Gateway*
DNS1*
DNS2
Cabling Information

This information will be used to determine cable lengths needed for a successful installation.
Distance between office/network location and main menu board wall?
Distance between office/network location and side wall or alternate location menu board wall?
Main Menu Board Wall

The Main Menu Board wall is considered the wall behind the cashiers where the main screens will be installed. The wall must be at least 24 inches tall and 11 feet wide for three screens, or 15 feet wide for four screens
Orientation of the menu board screens*

Landscape/HortizontalPortrait/Vertical
Height of main menu board wall:*
Length of main menu board wall:*
Please confirm that there is 1 ethernet cable per display running from office/network area to the menu board wall?**

YesNo
If there is an existing menu board, is it hard wired?*

YesNoN/A
What is the material of the wall?*

ConcreteTileDrywallWoodOther
Will any special tools be required to drill into the wall?

YesNo
If Yes, please explain
What type of studs are in the wall?*

WoodMetal
Approximately, how far apart are the studs?*
Side Wall or Alternate Location Menu Board Wall

This is the wall at either end of the counter or an alternate location inside the site. Please fill out the below information if a display will be installed in a different location from the main menu board wall.
Orientation of the menu board screens

Landscape/HortizontalPortrait/Vertical
Height of side wall or alternate location menu board wall:
Length of side wall or alternate menu board wall:
Please confirm that there is 1 ethernet cable per display running from office/network area to the side wall or alternate menu board wall?

YesNo
If there is an existing menu board, is it hard wired?

YesNoN/A
What is the material of the wall?

ConcreteTileDrywallWoodOther
Will any special tools be required to drill into the wall?

YesNo
If Yes, please explain
What type of studs are in the wall?

WoodMetal
Approximately, how far apart are the studs?
Pictures

This information will be used to help determine if any additional follow up is required prior to installation
Picture of the main menu board wall from far enough way to see the entire wall*

Browse Files

Cancelof
Picture of the Side Wall or Alternate Location from far enough away to see the entire wall(if applicable)

Browse Files

Cancelof
The office/network area where we will be connecting the displays to the network*

Browse Files

Cancelof
The entire front service area as far away as possible*

Browse Files

Cancelof
Survey Completion Information
Please provide any additional notes or comments:
Company Name:*
Name of Person completing Survey:*

First NameLast Name
